| + | [* black] Take out the shaft enough to give some clearance on the left end (End nearest to motor). Weld one of the end washers on, staying clear of the second washer. |
|---|---|
| + | [* black] Push the shaft back in and measure and mark a distance on the other side of the shaft to put a cotter pin through. |
| + | [* black] Carefully take out the shaft all the way and drill the hole for the cotter pin. |
| + | [* black] Fit the shaft back with all washers and lid in places, ensure the cotter pin fits. |
| + | [* black] Check the motion in the hinge by lifting it up and closing again. |
